Download: C-Fit Easy P6.67-P8 outdoor LED display screen Specification Sheet
C-Fit Easy P6.67-P8 Outdoor LED Display: 2026 Specifications
Choosing between C-Fit Easy P6.67 and P8 starts with what the audience needs to read and how close they will be. The downloadable specification sheet above covers several cabinet configurations, including standard and high-brightness versions. Use it alongside the C-Fit Easy outdoor LED display product page, then identify the exact cabinet and operating mode in your quotation. This keeps the pixel pitch, dimensions, brightness and power figures together as one configuration.
How to compare P6.67 and P8
| Item | P6.67 | P8 | Why it matters |
|---|---|---|---|
| Nominal pixel pitch | 6.67 mm | 8 mm | Smaller spacing gives more pixels within the same display area. |
| Cabinet resolution | 144 × 144 pixels | 120 × 120 pixels | P6.67 provides 44% more pixels per cabinet, calculated from these resolutions. |
| Module resolution | 48 × 48 pixels | 40 × 40 pixels | Match content dimensions to the assembled screen’s pixel map. |
| Brightness and power | Use the selected variant and mode | Use the selected variant and mode | The PDF includes different output and power configurations; compare equivalent operating conditions. |
If your creative uses small text or detailed images at closer viewing positions, test P6.67 first. If the audience is farther away and the content uses larger graphics, compare P8 with the same creative before paying for extra pixels. The pixel pitch guide explains how to run that comparison.
What Should Be Confirmed Before Quoting a P6.67 or P8 Cabinet?
Send the supplier your screen dimensions, viewing positions, daylight exposure and proposed service access. Ask for a quote that names the pitch, cabinet size and brightness mode, with matching average and maximum power figures. The C-Fit Easy series overview helps compare cabinet options; the outdoor billboard TCO guide helps turn the selected configuration into an operating budget.
Which documents should accompany the final specification?
Keep the selected model sheet, cabinet layout, installation and maintenance instructions, and any project-required compliance documents with the quotation. The linked PDF contains multiple versions, so ask the supplier to identify the applicable pages and resolve any differences before those values enter the final project schedule.
