Download: C-Fit Easy P10-P16 outdoor led display screen Specification Sheet
Engineered for Durability & Future-Proof Scalability: C-Fit-Easy Series
For a long-view billboard, compare P10 and P16 using the same display area and the content people need to read. The linked specification file contains multiple C-Fit Easy cabinet versions; select the exact version before comparing brightness or power. The C-Fit Easy long-view outdoor display page provides the product context.
Compare P10 and P16 on the same cabinet size
| Item | P10 | P16 |
|---|---|---|
| Nominal pixel pitch | 10 mm | 16 mm |
| Cabinet resolution | 128 × 96 pixels | 80 × 60 pixels |
| Module resolution | 32 × 32 pixels | 20 × 20 pixels |
| Pixels per cabinet | 12,288 | 4,800 |
For these formats, P10 has 2.56 times as many pixels in the same cabinet area. That calculated difference helps compare detailed creative; P16 may still fit a long viewing distance and large, simple messages. Test the actual content using the pixel-pitch selection guide.
What Should Be Confirmed Before Quoting a P10 or P16 Cabinet?
Send the proposed screen dimensions, viewing distance, daylight exposure and service access. Ask the supplier to name the cabinet version, pitch, operating brightness and matching average/maximum power figures. Then use the billboard TCO guide to compare the installed and running costs.
Which documents should accompany the quotation?
Keep the selected specification pages, cabinet layout, installation and service instructions, and any project-required compliance documents with the quote. Brightness and construction details vary within the file, so identify the applicable version rather than combining the most attractive values from different models.
