C-Tra-KXB Gantry VMS

Robust, high-brightness DIP gantry VMS for mainline highways.

C-Tra-KXB (Gantry Series) is Chipshow’s flagship overhead LED traffic sign designed for new highway projects and large-span portals. Featuring DIP510 optical lens technology, it delivers up to 20,000 nits brightness and 250m+ visibility. The robust galvanized iron cabinet (<60kg/m²) ensures structural stability for full-width gantries while maintaining IP65 protection against harsh road environments.

Categories: , ,
C-Tra-KXB Gantry VMS
Robust, high-brightness DIP gantry VMS for mainline highways. C-Tra-KXB (Gantry Series) is Chipshow’s flagship overhead LED traffic sign designed for new highway projects and large-span portals. Featuring DIP510 optical lens technology, it delivers up to 20,000 nits brightness and 250m+ visibility. The robust galvanized iron cabinet (<60kg/m²) ensures structural stability for full-width gantries while maintaining IP65 protection against harsh road environments.
Learn More
Specification

Pixel Pitch  P16 / P20 / P25 / P31.25 / P33.33

Brightness 12,000 – 20,000 nits (Lens Optics)

Visibility  ≥200 m dynamic / ≥250 m static

Cabinet Weight  <60 kg/m² (Galvanized Steel)

Protection  IP65 Front / IP54 Rear (Fully Sealed Modules)

≥12,000 nits traffic-optimized optics for direct-sun legibility.

Strong penetration at 250m ensures safety in heavy fog.

Robust <60 kg/m² steel design for maximum structural stability.

IP65 Sealed Modules resist rain, dust, and highway road spray.

DIP510 Technology offers superior heat dissipation and longevity.

Independent Module Access reduces maintenance lane-closure time.

Get Quote Now
Spec Sheet
Share
  • Description
  • Specification
  • Application
  • Solution
  • FAQs
chipshow

Optical Performance & Brightness

Powered by large-chip DIP510 LEDs with optical lenses, the display achieves brightness up to 20,000 nits (on P25/P31 models) and standard 12,000 nits on P16/P20. This ultra-high contrast ensures speed limits and warnings cut through glare, even when facing the sun directly on wide multi-lane gantries.
chipshow

Long-Range Penetration (Safety)

Designed as a primary guidance device, the C-Tra-KXB guarantees text legibility at 200m+ (dynamic) and 250m+ (static). Its focused beam angle penetrates fog and rain, giving drivers on high-speed motorways sufficient reaction time to changing road conditions.
chipshow

Robust Galvanized Structure

Built with a galvanized iron cabinet, this series balances durability with cost-efficiency. Weighing <60 kg/m², it is significantly lighter than legacy cabinets (often >80kg), reducing static load on new gantries while providing the rigidity needed for typhoon-prone coastal areas.
chipshow

Harsh Environment Protection

The system features fully sealed IP65 modules, protecting internal components from dust, driving rain, and corrosive exhaust fumes. With an operating range of −20°C to +50°C, it performs reliably in environments ranging from freezing northern bridges to scorching desert highways.
chipshow

Energy Efficient Drive

Despite its high brightness, the optical lens technology focuses light only where needed (the road), reducing wasted light spill. Combined with an energy-saving drive IC, it maintains lower average power consumption than traditional wide-angle DIP screens, lowering long-term OpEx.
chipshow

Installation & Integration

Standard cabinet formats (1024×1024 mm / 1280×1280 mm) allow for modular assembly of full-span gantry signs. The system supports standard HUB75 and mainstream controllers (Chipshow/Nova), ensuring seamless integration into existing Traffic Management Centers (TMC) and ITS networks.

Send a Comment

Checkboxes
Chat on WhatsApp

Product Highlight

chipshow

Up to 20,000 nits

Lens optics ensure visibility under direct sun and heavy fog.
chipshow

Robust Steel Body

Galvanized iron construction for maximum stability on large gantries.
chipshow

250m+ Readability

Long-distance legibility for high-speed highway safety.
chipshow

IP65 Sealed Modules

Proven protection against rain, dust, and road salt spray.

Service Support

chipshow
End-to-End Project Support
From design to installation, we handle every step for you.
chipshow
Customization for Every Scenario
Tailored LED screens for any location or shape.
chipshow
Reliable Quality & Smart Maintenance
Stable performance, simple upkeep, and long lifespan.
chipshow
Global Service & Fast Response
Fast delivery and responsive service worldwide.

Related Solution

chipshow

Complete Highway Guidance System

Deploy C-Tra-KXB Gantry VMS for mainline traffic control, and pair it with C-Tra-KXB Lightweight VMS for ramp/F-pole signage. For toll plazas, integrate our ETC Lane Displays to create a unified, end-to-end Intelligent Transportation System (ITS).

Frequently Asked Questions

From specs and compatibility to warranty and support, our FAQ covers everything you need to know to get the most out of your experience.
chipshow
+86 18148555033
chipshow
[email protected]
chipshow
5F Tower C,Baoshi Technology Park,Baoshi Road,Shiyan Street,Bao'an District.Shenzhen City China 518102
How does the gantry VMS perform in regions with extreme sunlight or heavy fog, like the Middle East or coastal highways?
In areas prone to intense desert glare or dense coastal fog, exceptional visibility is critical for road safety. This variable message sign (VMS) utilizes advanced DIP510 optical lens technology, delivering an ultra-high brightness of up to 20,000 nits. This ensures traffic messages remain clearly readable from over 250 meters away. Additionally, it strictly complies with the EN12966 optical class standards, providing high contrast without causing dangerous glare to drivers, regardless of extreme weather conditions.
