C-Vent P16 Outdoor Ventilation Advertising LED Display

Advantages of Ventilation display : Easy：Front-maintenance module is convenient for disassembly and assembly Ultrathin design: It is ultra light and ultrathin and requires low load bearing. It has ultrathin design, the thickness of the whole cabinet is only 90mm and it is 50mm thinner than the routine cabinet that makes installation more easier. Low windage: Because the screen is ventilation, it reduce the windage and can  save the structure costs. Good ventilation: Its transmittance is over 7% and gain the homogeneous emission.Do not need to use air conditioning fan and save cost. Strong adaptability:waterproof, dustproof and airproof design. Environmental protection and energy saving.

Features: 1 Intelligent lighting: the C-Fit-Pole series can automatically adjust the color and brightness to optimize the lighting effects and energy consumption, according to local conditions (e.g. regional climates, environmental brightness); 2 Intelligent monitoring: the C-Fit-Pole series can detect smoke, humidity, temperature, and PM 2.5; and it also supports facial recognition, remote power switches, and audio-visual interaction; 3 News broadcast: the smart light pole is equipped with a module that has the network broadcasting function; in case of emergency, the light pole can broadcast news to people in its nearby region; 4 4G/5G networking remote control: with the C-Fit-Pole series, you can establish a large-scale network in which the number of the pole LED screens is not limited; in addition, its high-speed data transfer makes it easy to send animations, videos, and high-resolution pictures; 5 Modular design: the C-Fit-Pole series adopts LED modules that support front-&-rear service, which provides convenience for users to install and maintain; 6 High protection grade: the cabinets are made of die-cast magnesium alloy, the front of the cabinets reaches IP65 protection grade, and the rear reaches IP64;

Features 1 The pole LED screens are supported by steel hoops mounted on lamp poles; so the installation is quite simple and quick; 2 This series offers you a smart method to implement cluster control of LED pole screens - you can remotely, massively control all the pole LED screens through 5G networking; 3 With an IP65 protection rating, the Pole LED screens can be suitable for outdoor use throughout the year; 4 The print ads on the screens are replaceable; so when it comes to print advertising, the screens can be repeatedly used after installation; 5 The C-Pole series can produce a strong visual impact on the eyes – you can light up the pole screens to display ads 24 hours a day; 6 There is a large information capacity; you can create the rich programs by yourself and play them based on a schedule that you set; it is widely adopted as a low-cost, environmentally friendly advertising solution;

Features: 1 High brightness - every LED module adopts LED beads with optical lens filters; the brightness level can reach 8000 CD /㎡; 2 Energy-saving – compared with LED display screens that have a similar specification, this series can save more than 65% of energy; 3 Ultra-strong penetration: it can show drivers clear images, even though they are driving 120 KM per hour, in a far distance that is more than 210meters, or in foggy weather; 4 High protection - every LED module and every cabinet are fully enclosed, and both the front and rear of the screen are IP65 rated; 5 Quick maintenance – the simple and quick assemble and disassemble design will save you a lot of time significantly during installation and maintenance; 6 Ultra-light: the weight of every finished cabinet is less than 35kg/㎡, therefore, it does not have a strict requirement on the strength of the supporting structure, and is quite suitable as large LED display screens on highways; 7 High reliability: to ensure the reliability and stability of the screen under all kinds of bad weather conditions, the screen adopts high-quality LED beads, IC, and power supply units;

1.  High brightness and energy saving: 3.2/4.2V low-voltage power supply, 4535 3in1 high brightness Leds, brightness ≥ 10000CD/㎡; The brightness can be adjusted automatically; 2.  HD display: Above 210 meters (vehicle speed 120) in dynamic, and can still be clearly visible in more than 250 meters in static distance in foggy weather; It can still display the road conditions in high definition to warn and guide vehicles to pass safely and efficiently; 3.  Efficient heat dissipation: Large flow negative pressure heat dissipation in the cabinet, efficient heat discharge, and more stable operation of LED display; 4.  Solar charging+9.6KWH large capacity battery, which can continuously power on the LED display 365 days a year; 5.  Hydraulic lifting+ rotating structure; The whole screen hovers at 1M height and 360 ° to play information at any height and angle. 6.  Double safety towing structure, 10mm safety chain, 80 level towing hook ring with safe and convenient dragging. 7.  7-core signal connector can control EMARK certified trailer indicator, brake light, turn light and side light in the whole vehicle. 8.  Support GPS positioning; Support U disk/mobile phone/tablet/computer/4G/WiFi playback; Support video and picture playback such as MP4/AVI/jpg/; 9.  It is mainly used for high-speed gantry and F frame traffic guidance; Safety warning signs for road repair vehicles, cleaning vehicles, sanitation vehicles and other road operation vehicles.

High brightness and energy saving: 2.8/3.8V low-voltage power supply, ICE high brightness lamp, automatically adjust the brightness; HD display: Above 210 meters (vehicle speed 120) in dynamic, and can still be clearly visible in more than 250 meters in static distance in foggy weather; It can still display the road conditions in high definition to warn and guide vehicles to pass safely and efficiently; Efficient heat dissipation: Large flow negative pressure heat dissipation in the cabinet, efficient heat discharge, and more stable operation of LED display; Solar charging+9.6KWH large capacity battery, which can continuously power on the LED display 365 days a year; Hydraulic lifting+ rotating structure; The whole screen hovers at 1M height and 360 ° to play information at any height and angle. Double safety towing structure, 10mm safety chain, 80 level towing hook ring with safe and convenient dragging. 7-core signal connector can control EMARK certified trailer indicator, brake light, turn light and side light in the whole vehicle. Support GPS positioning; Support U disk/mobile phone/tablet/computer/4G/WiFi playback; Support video and picture playback such as MP4/AVI/jpg/; It is mainly used for high-speed gantry and F frame traffic guidance; Safety warning signs for road repair vehicles, cleaning vehicles, sanitation vehicles and other road operation vehicles.

Features: 1 Practicalness: the modules adopt a simple and practical design that is characterized by convenient fast locks and firm handles; 2 Front and rear service: the LED screens can be assembled, disassembled, and maintained quickly from both front and rear; 3 Strong and durable: every handle is integrated with horizontal and horizontal stiffeners to avoid deformation during fixed installation, and hanging installation for rental use; 4 Magnetic design (optional): you can opt to use the upper and down magnets between cabinets to position and install quickly; from the point of installation for rental services, this type of LED screen is very cost-effective; 5 Hot selling: so far, more than 5000㎡ of the C-Lite-Plus series LED screens have been sold all over the world; we guarantee enough stocks and fast delivery; 6 Wide application: the C-Lite-Plus series is quite suitable as rental LED display screens for theater stages, exhibition shows, product launches, commercial squares, large sports events, etc;

C-Vent, ventilating leads to high heat radiating, no need fan or air-conditioner, reducing 50% energy consumption. Advantages: 1. Ventilating: Air can transmit the display body directly, ventilation rate 50%. 2. No light penetration: Penetrating design without light penetration, no harm to contrast ratio, full conservated the display effect. 3. Front access: Front-maintenance module is convenient for disassembly and assembly. 4. Low windage resistance: Lower requirement of steel structure, 35% structure cost saved. 5. Air-conditioner exonerated: Ventilating leads to high radiating, no need fan or air-conditioner. 6. Energy-saving & environmental protection: Low power consumption, 50% energy saving. 7. High applicability: IP65 fully sealing design, rain proof, dust proof, adapted to all weather surroundings.
